MSJ Series Chain Conveyor
MSJ type submerged scraper conveyor for soda ash is specially used for conveying powder, granular and small lump materials which are easy to flow, such as soda ash (especially hot soda ash above 150°) horizontally or with slight inclination (a≤10°). The machine is well sealed, and can automatically adjust the thermal expansion and contraction of the conveying chain, the process layout is flexible, and it can be fed and discharged at multiple points. The machine adopts forging chain as traction member, with low power consumption and long life of scraper chain, conveying distance Lmax=80m, conveying capacity Qmax= 575m%h.
Key word:
Category:
Product description
MSJ type submerged scraper conveyor for soda ash is specially used for conveying powder, granular and small lump materials which are easy to flow, such as soda ash (especially hot soda ash above 150°) horizontally or with slight inclination (a≤10°). The machine is well sealed, and can automatically adjust the thermal expansion and contraction of the conveying chain, the process layout is flexible, and it can be fed and discharged at multiple points. The machine adopts forging chain as traction member, with low power consumption and long life of scraper chain, conveying distance Lmax=80m, conveying capacity Qmax= 575m%h.
