GCJ Series Steel Belt Type Slag Removal Machine
The GCJ series steel belt slag remover is the key equipment for the dry slagging system of power plant boilers and is installed at the outlet of the slagging device at the bottom of the furnace. T
Key word:
Category:
Product description
The GCJ series steel belt slag remover is the key equipment for the dry slagging system of power plant boilers and is installed at the outlet of the slagging device at the bottom of the furnace. The equipment mainly consists of conveying steel belt assembly, cleaning scraper assembly, box structure etc. The steel belt conveying assembly consists of high temperature resistant conveying mesh belt, carrier roller, carrier wheel, lateral limiting wheel, driving mechanism, tensioning mechanism, etc.; the cleaning scraper assembly consists of chain, scraper, carrier wheel, driving mechanism, tensioning mechanism, etc.; there are adjustable air inlets on the outside of the box and two main air inlet holes on the top of the box, which can be adjusted according to the slag discharge volume; there is an access door at the head and tail of the steel belt slag removal machine, which is used for a short period of time for the The steel belt and cleaning chain can be maintained for a short period of time. The tensioning of the conveyor belt and the cleaning scraper is carried out hydraulically, with a common set of pressure source and hydraulic shut-off door, and with an energy storage tank. The function of the steel belt slag removal machine is to continuously receive and deliver high temperature furnace slag and to further burn and cool the furnace slag in the process of conveying, the conveying speed of the steel belt can be adjusted according to the size of the furnace slag.
